Project TMV 27A - a modern two-storey house with a convenient layout and a covered terrace. Composition of the premises: entrance hall, hall, kitchen-living room, 4 bedrooms, 3 bathrooms, dressing room, storage room, boiler room.
First floor plan
![](/_ipx/f_webp,w_1000/storage/uploads/2024/4/ElCluRXFAmZwCksvagP4kYfbVH7H0MMSAoDOgfzs.png)
Second floor plan
![](/_ipx/f_webp,w_1000/storage/uploads/2024/4/1fq2qDht01QFm5HPDoQSJUZsxhRpGKDL45ZVixHO.png)
Roof plan
![](/_ipx/f_webp,w_1000/storage/uploads/2024/4/HUJHoagLctdjBTUaJOcU8AaPDpITDlfps9R4W8qA.png)
Facades
![](/_ipx/f_webp/storage/uploads/2024/4/EdnE1oUendEmS0megL7z0yUXFQ63M58ofJEqhoIc.jpg)
![](/_ipx/f_webp/storage/uploads/2024/4/H4GggksmIKOgmaKNDvJaq7bx2krKRagM9FETYiJa.jpg)
![](/_ipx/f_webp/storage/uploads/2024/4/YT1I92PavCZVpc9PWnSWI0HNZV6z2wTbxP1D7g4K.jpg)
![](/_ipx/f_webp/storage/uploads/2024/4/KsV5jqEiKvo04Lgnit3jOUwRjuX2jXKeu6Y0IG8X.jpg)
General characteristics
Total area 197.86 m2
Area without terraces 191.89 m2
1st floor area 99.22 m2
2nd floor area 98.64 m2
Living area 81.49 m2
Dimensions 12.34 x 14.93 m
1st floor height 3.00 m
2nd floor height 2.80 m
Building area 157.64 m2
Roof area 250.87 m2
Roof pitch 16 - 25 °
House height 9.34 m
Bedrooms 4
Bathrooms 3
Alteration are possible
Author's title TMV27A
Exterior walls
aerated concrete 400 mm + insulation 100 mm
Foundations
monolithic strip
Overlaps
reinforced concrete slab
Roofing material
metal tile
